Electric Rotary Degassing Unit 500-1000 Kg/h Capacity 0.1MPa Max Pressure

Electric Rotary Degassing Unit 500-1000 Kg/h Capacity 0.1MPa Max Pressure
Electric Rotary Degassing Unit 500-1000 Kg/h Capacity 0.1MPa Max Pressure
Electric Rotary Degassing Unit 500-1000 Kg/h Capacity 0.1MPa Max Pressure Electric Rotary Degassing Unit 500-1000 Kg/h Capacity 0.1MPa Max Pressure

Large Image :  Electric Rotary Degassing Unit 500-1000 Kg/h Capacity 0.1MPa Max Pressure

Product Details:
Brand Name: Hydeb
Certification: ISO CE
Model Number: BDU
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: ＞30000USD
Packaging Details: Wooden Box
Delivery Time: 50-60 Days
Payment Terms: 30%+70%
Supply Ability: 500 Sets Per Year
Contact Now

Electric Rotary Degassing Unit 500-1000 Kg/h Capacity 0.1MPa Max Pressure

Description
Power Source: Electric Weight: 500 Kg
Gas Inlet Pressure: 0.4-0.6 MPa Max Pressure: 0.1MPa
Cooling Water Consumption: 5 L/min Gas Type: Argon
Dimension: 1200mm X 800mm X 1500mm Power Supply: 380V/50Hz
Highlight:

box type rotary degassing unit

,

low cooling water consumption degasser

,

0.1MPa pressure rotary degassing unit

Degassing with Box Type In-line Rotary Degassing Unit Max Pressure 0.1MPa Low Cooling Water Consumption 5 L/min
Product Description
The Rotary Degassing Unit efficiently removes hydrogen and alkali from molten metal during production, ensuring high-quality results with a degassing efficiency of 60%. Operating at temperatures up to 1500℃ with a capacity of 500-1000 Kg/h, this electric-powered unit delivers consistent performance while maintaining low cooling water consumption of just 5 L/min.
Key Features
  • Product Name: Rotary Degassing Unit
  • Compact dimensions: 1200mm × 800mm × 1500mm
  • Efficient cooling water consumption: 5 L/min
  • Uses argon gas for degassing
  • Capacity range: 500-1000 Kg/h
  • Maximum pressure: 0.1MPa
  • Effective hydrogen and alkali removal
Technical Specifications
Parameter Value
Cooling Water Pressure 0.2-0.4 MPa
Gas Consumption 10-15 L/min
Capacity 500-1000 Kg/h
Max Pressure 0.1MPa
Power Source Electric
Total Power <47 kW
Gas Inlet Pressure 0.4-0.6 MPa
Degassing Efficiency 60%
Electric Rotary Degassing Unit 500-1000 Kg/h Capacity 0.1MPa Max Pressure 0
Applications
Hydeb's Box Type In-line Rotary Degassing Unit (Model BDU) is ISO and CE certified for use in foundries, die casting facilities, and metal casting workshops. Its 60% degassing efficiency ensures porosity-free castings by effectively removing hydrogen from molten aluminum, resulting in superior product quality and durability.
Customization Options
Brand Name: Hydeb
Model Number: BDU
Certification: ISO CE
Minimum Order Quantity: 1
Price: >30000USD
Packaging: Wooden Box
Delivery Time: 50-60 Days
Payment Terms: 30%+70%
Annual Supply Capacity: 500 Sets
Key Features: Molten Aluminium, Rotor Degassing box, Impurity Removal
Support and Services
Our technical support team provides comprehensive assistance for installation, operation, and troubleshooting. We offer maintenance plans, spare parts availability, and on-site repairs to ensure optimal performance of your degassing unit.
