0-99 Min Refinement And Degassing Time Aluminum Refining Degassing Machine For Aluminum Production

Certification
China Jinan Hydeb Thermal Tech Co., Ltd. certification
China Jinan Hydeb Thermal Tech Co., Ltd. certification
I'm Online Chat Now

0-99 Min Refinement And Degassing Time Aluminum Refining Degassing Machine For Aluminum Production

0-99 Min Refinement And Degassing Time Aluminum Refining Degassing Machine For Aluminum Production
0-99 Min Refinement And Degassing Time Aluminum Refining Degassing Machine For Aluminum Production
0-99 Min Refinement And Degassing Time Aluminum Refining Degassing Machine For Aluminum Production 0-99 Min Refinement And Degassing Time Aluminum Refining Degassing Machine For Aluminum Production 0-99 Min Refinement And Degassing Time Aluminum Refining Degassing Machine For Aluminum Production 0-99 Min Refinement And Degassing Time Aluminum Refining Degassing Machine For Aluminum Production

Large Image :  0-99 Min Refinement And Degassing Time Aluminum Refining Degassing Machine For Aluminum Production

Product Details:
Place of Origin: Jinan, China
Brand Name: HYDEB
Certification: CE ISO9001
Model Number: XCP220-1
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: 7888-9998USD/set
Packaging Details: Standard exporting package
Delivery Time: 45 workdays
Payment Terms: L/C, T/T
Supply Ability: 100 sets per year

0-99 Min Refinement And Degassing Time Aluminum Refining Degassing Machine For Aluminum Production

Description
Frequency Hz: 50Hz Total Power KW: 4kW
Net Weight: 600kg Voltage V: 380V
Refining Flux Particle Size Mm: ≤5 Power Supply Phases: Three-phase Four-wire
Refined Gas Pressure MPa: Adjustable From 0.1 To 0.6 Refined Flux Powder Spraying Amount G/min: 0~350
Highlight:

0-99 min Degassing Machine

,

Aluminum Production Refining Degassing Machine

,

Aluminum Production Degassing Machine

0-99 Min Refinement And Degassing Time Aluminum Refining Degassing Machine For Aluminum Production 0

Product Description:

Molten Aluminium Refining and degassing slag removal machine Equipment Stationary Rotary Degassing and Fluxing Unit
The molten aluminum refining and degassing equipment is used to remove gases (mainly hydrogen) and oxides (aluminum slag) from molten aluminum. The equipment can be applied of refining treatment of molten aluminum in a crucible or road molten aluminum transfer ladle.

◆ Divided into several basic models, including mobile type , stationary type and suspending type.

◆ Divided into types such as “Degassing” type and “Degassing + Fluxing ” type.

0-99 Min Refinement And Degassing Time Aluminum Refining Degassing Machine For Aluminum Production 1

Features:

◆ Able to remove gases (mainly hydrogen) and oxides from the molten aluminum more effectively. The equipment has the advantages of both gas refining and flux-refining. After rotary injection, the hydrogen concentration in molten aluminum alloys will be reduced below 0.1ml/100g, the pinhole degree will reach up to level 1, the density will be less than 1, and a stable effect will be achieved.

◆ Low metal loss. After proper flux-refining, there is less dross on the melt surface and the dross is loose. The metal is rarely encased and little metal is taken out during slag removal.

◆ Low refining agent consumption and stable feeding.

◆ Equipped with an anti-falling mechanism, a refining agent material level measuring and an air channel leakage detector.

◆ Multiple technological processes can be executed. When used with different functions of fluxes, it can be used for high-efficiency modification, degassing and slag removal.

◆ The rotor bearing is a high-temperature bearing, not needing to be air-cooled. The spindle can work without stop at a high temperature of 200°C.

◆ Automatic operation, site working conditions are significantly improved.

0-99 Min Refinement And Degassing Time Aluminum Refining Degassing Machine For Aluminum Production 2

Technical Parameters:

Product Attribute Technical Parameter
Product Name Rotary Degassing Unit
Refined Flux Powder Spraying Amount 0~350 g/min
Voltage 380V
Refined Gas Pressure Adjustable From 0.1 To 0.6 MPa
Refined Gas Flow Rate Adjustable From 15 To 30 L/min
Total Power 4kW
Net Weight 600kg
Frequency 50Hz
Refinement and Degassing Time 0 To 99 min
Refined Gas Purity ≥99.996%
Graphite Rotor Speed Frequency Conversion Adjustment 0-600 r/min
Product Type Smelting Purification Equipment, Furnace side refining equipment, Refining equipment in front of furnace
0-99 Min Refinement And Degassing Time Aluminum Refining Degassing Machine For Aluminum Production 30-99 Min Refinement And Degassing Time Aluminum Refining Degassing Machine For Aluminum Production 40-99 Min Refinement And Degassing Time Aluminum Refining Degassing Machine For Aluminum Production 5
