45KW Process Of Refining Aluminum Degassing On Line Unit 750 Deg Launder Type

45KW Process Of Refining Aluminum Degassing On Line Unit 750 Deg Launder Type
45KW Process Of Refining Aluminum Degassing On Line Unit 750 Deg Launder Type
45KW Process Of Refining Aluminum Degassing On Line Unit 750 Deg Launder Type 45KW Process Of Refining Aluminum Degassing On Line Unit 750 Deg Launder Type 45KW Process Of Refining Aluminum Degassing On Line Unit 750 Deg Launder Type

Large Image :  45KW Process Of Refining Aluminum Degassing On Line Unit 750 Deg Launder Type

Product Details:
Place of Origin: China
Brand Name: Hydeb
Certification: CE,ISO9001,ISO14001,IS45001,High-tech Enterprise,Intellectual Property,Patents
Model Number: LDU-I
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $30000-$60000/set
Packaging Details: Wooden Case or Pallet
Delivery Time: 50 working days
Payment Terms: T/T
Supply Ability: 20 sets per year

45KW Process Of Refining Aluminum Degassing On Line Unit 750 Deg Launder Type

Description
Key Name: On-Line Unit Siliver Launder Type Degasser Unit For Continuously Producing Aluminum Billets Function: Purity Aluminum Alloy
Rotor Material: Graphite Protector Tube Material: Graphite
Rotor No.: 1 Totally Power: < 45KW
Color: Siliver Heating Elements: Spiral SIC Heating Elements
High Light:

45KW Aluminum Degassing On Line Unit

,

Aluminum Degassing 750 deg

,

process of refining aluminium For Aluminum

On-Line Unit Siliver Launder Type Degasser Unit For Continuously Producing Aluminum Billets



Molten Aluminum Launder Type One Graphite Rotor In-line Rotory Degassing Equipment



1.  Company Introduce



-- Established in January 2003, and now has 56 employees

-- Sales of 50 million RMB in 2021

-- Focus on one industry -- "aluminum casting"

-- Has a complete product line of aluminum casting equipment, all products are independent research

and development, manufacturing

-- aluminum melting and holding, transportation, ladle preheating, aluminum liquid refining, aluminum liquid

hydrogen measurement, until aluminum solution aging treatment equipment



2. Degassing Unit Description



The LDU has higher degassing efficiency because degassing rotors are mounted between the melting furnace and casting machine in the length direction of the launder and the degassing zone is partitioned into several parts for multilevel in-line degassing. The number of rotors depends on the flow rate of molten aluminum



3.  Mainly Technical Data



Items Data
Maximum temperature of molten aluminum 750℃
Launder shell surface temperature ≤60℃
Launder lining life ≥12 months
Rotor speed 100-600rpm
Inert gases High-purity N2, high-purity Ar
Degassing efficiency

When it is not greater than the maximum flow rate, the inlet hydrogen content is ≤0.30ml / 100gAl, when the aluminum liquid is 700-740 ℃, the hydrogen content after degassing is ≤0.22ml / 100g

-Degassing efficiency≥35% when hydrogen content at the inlet>0.30ml/100g-Al.

Power supply 380V AC 50Hz, ≤10KVA



4. Types



No. Of Rotor 1 2 3 4
Type LDU-I LDU-II LDU-III



LDU-IV



5. Shipping



45KW Process Of Refining Aluminum Degassing On Line Unit 750 Deg Launder Type 0



45KW Process Of Refining Aluminum Degassing On Line Unit 750 Deg Launder Type 1



6. FRQ



Q1: I know nothing about this machine, what kind of machine I should choose?
Very easy. We will email you an inquiry form for making sure your real need. Or just tell us what you want to
do by using this machine, then let us give you perfect solutions and suggestions.


Q2: When I get this machine, but I don’t know how to use it. What should I do?
We will send pictures or video and English manual with the machine. If you still have some doubts, we can talk by
Telephone/ Skype / Whatsapp / Weichat/ E-mail.


Q3: If some problems happen to this machine during warranty period, what should I do?
We will supply free parts during machine warranty period if machine have some problems (except spare parts).
While we also supply free life long after-sales service. So any doubts, just let us know, we will give you solutions.
