Hot Top Aluminum Billet Casting Machine 3 Rotors Degassing Machine For Molten Aluminium

Hot Top Aluminum Billet Casting Machine 3 Rotors Degassing Machine For Molten Aluminium
Hot Top Aluminum Billet Casting Machine 3 Rotors Degassing Machine For Molten Aluminium Hot Top Aluminum Billet Casting Machine 3 Rotors Degassing Machine For Molten Aluminium Hot Top Aluminum Billet Casting Machine 3 Rotors Degassing Machine For Molten Aluminium Hot Top Aluminum Billet Casting Machine 3 Rotors Degassing Machine For Molten Aluminium Hot Top Aluminum Billet Casting Machine 3 Rotors Degassing Machine For Molten Aluminium

Large Image :  Hot Top Aluminum Billet Casting Machine 3 Rotors Degassing Machine For Molten Aluminium

Product Details:
Place of Origin: Jinan, China
Brand Name: HYDEB
Certification: CE ISO9001
Model Number: HD-2xxx
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: 40000USD/set
Packaging Details: Standard exporting package
Delivery Time: 45 workdays
Payment Terms: L/C, T/T, Western Union, MoneyGram

Hot Top Aluminum Billet Casting Machine 3 Rotors Degassing Machine For Molten Aluminium

Description
Static Aluminum Liquid Capacity Of Degassing Box Kg: 700 Weight: 200KG
Vacuum Degree: ≤-0.092MPa Total Power KW: KW < 45
Temperature Control: Digital Display Rated Molten Aluminum Flow Rate T/h: 10
Power Voltage V: 380±10% Inlet Molten Aluminum Temperature ℃: 700
High Light:

Molten Aluminium Degassing Unit

,

Hot Top Aluminum Billet Casting Machine

,

3 Rotors Degassing Machine

Product Description:

The Aluminum Degassing Machine is a specialized degassing tool for aluminium foundries, designed for efficient degassing of molten ingots. It is a powerful tool with a 3-phase power supply, 2X-70A vacuum pump, 380±10% power voltage, digital temperature control, and box cover lifting height of ≥950mm. It ensures a fast and effective nitrogen degassing process, to achieve a high-quality, consistent aluminium ingot. It is a reliable and durable device, with a long service life and minimal maintenance needs, making it perfect for all aluminium foundries.



Features:

  • Degassing Aluminum Casting Product: Aluminum Degassing Machine
  • Inlet molten aluminum temperature ℃: 700
  • Power Phase: 3
  • Box Cover Lifting Height: ≥950mm
  • Rated molten aluminum flow rate t/h: 10
  • Total Power kW: KW < 45
  • Degasser Alumina Product: Aluminum Degassing Machine
  • Degassing Aluminium Foundry Product: Aluminum Degassing Machine


Technical Parameters:

Technical Parameter Value
Rotor speed r/min 0 to 600
Temperature Control Digital Display
Weight 200KG
Vacuum Pump 2X-70A
Total Power kW KW < 45
Power Voltage V 380±10%
Power Phase 3
Inlet molten aluminum temperature ℃ 700
Frequency Hz 50
Box Cover Lifting Height ≥950mm


Applications:

The HYDEB HD-2xxx Aluminum Degassing Machine is a reliable and efficient product that can be used for inline degassing, aluminum degassing rotor product, and aluminum degassing melting furnace. With a static aluminum liquid capacity of 700 kg, the machine has a weight of 200KG and operates at 50 Hz. It also features a digital display for temperature control and an inlet molten aluminum temperature of 700℃.

The HYDEB HD-2xxx Aluminum Degassing Machine is equipped with advanced degassing technology, which helps to reduce the occurrence of porosity, gas holes, and other defects. Moreover, it improves the uniformity of molten aluminum, allowing for better casting quality and improved product performance. The machine also helps to reduce the cost of production and environmental pollution.

The HYDEB HD-2xxx Aluminum Degassing Machine is the ideal solution for aluminum degassing and melting applications. With its reliable and efficient performance, it can help to improve the quality of products and reduce production costs. It is the perfect choice for aluminum casting and degassing applications.

Hot Top Aluminum Billet Casting Machine 3 Rotors Degassing Machine For Molten Aluminium 0



Customization:

Custom Aluminum Degassing Machine

Brand Name: HYDEB
Model Number: HD-2xxx
Place of Origin: Jinan, China
Frequency Hz: 50
Inlet molten aluminum temperature ℃: 700
Power Phase: 3
Weight: 200KG
Vacuum Degree: ≤-0.092MPa

Features of Our Aluminum Degassing Machine:

  • Inline rotary degassing unit casting, nitrogen degassing machine
  • High degassing efficiency
  • Compact structure and small size
  • High vacuum degree
  • Degassing liquid machine equipment
  • Easy to operate and maintain


FAQ:

Q1: What is an Aluminum Degassing Machine?
A1: An Aluminum Degassing Machine is a machine designed to remove dissolved gases from molten aluminum prior to casting. The HYDEB Aluminum Degassing Machine, model HD-2xxx, is particularly suited for this purpose.
Q2: What are the advantages of using HYDEB Aluminum Degassing Machine?
A2: HYDEB Aluminum Degassing Machine is designed for high efficiency and low energy consumption. It can effectively reduce gas content, eliminate bubble and improve aluminum quality. It also has a long service life and can be used for a long time.
Q3: Where is the HYDEB Aluminum Degassing Machine manufactured?
A3: The HYDEB Aluminum Degassing Machine is manufactured in Jinan, China.
Q4: What types of aluminum can be degassed with the HYDEB Aluminum Degassing Machine?
A4: The HYDEB Aluminum Degassing Machine is suitable for degassing aluminum alloys and other aluminum materials.
Q5: What is the power consumption of the HYDEB Aluminum Degassing Machine?
A5: The power consumption of the HYDEB Aluminum Degassing Machine is about 5kw.
