Graphite Rotor Online Liquid Degassing System For Aluminium Billet Casting Machine

Certification
China Jinan Hydeb Thermal Tech Co., Ltd. certification
China Jinan Hydeb Thermal Tech Co., Ltd. certification
I'm Online Chat Now

Graphite Rotor Online Liquid Degassing System For Aluminium Billet Casting Machine

Graphite Rotor Online Liquid Degassing System For Aluminium Billet Casting Machine
Graphite Rotor Online Liquid Degassing System For Aluminium Billet Casting Machine Graphite Rotor Online Liquid Degassing System For Aluminium Billet Casting Machine Graphite Rotor Online Liquid Degassing System For Aluminium Billet Casting Machine Graphite Rotor Online Liquid Degassing System For Aluminium Billet Casting Machine Graphite Rotor Online Liquid Degassing System For Aluminium Billet Casting Machine Graphite Rotor Online Liquid Degassing System For Aluminium Billet Casting Machine

Large Image :  Graphite Rotor Online Liquid Degassing System For Aluminium Billet Casting Machine

Product Details:
Place of Origin: Jinan, China
Brand Name: HYDEB
Certification: CE ISO9001
Model Number: HD-2xxx
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: 35000USD/set
Packaging Details: Standard exporting package
Delivery Time: 45 workdays
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 60 sets per year

Graphite Rotor Online Liquid Degassing System For Aluminium Billet Casting Machine

Description
Power Voltage V: 380±10% Power Phase: 3
Weight: 200KG Frequency Hz: 50
Rotor Speed R/min: 0~600 Inlet Molten Aluminum Temperature ℃: 700
Static Aluminum Liquid Capacity Of Degassing Box Kg: 700 Box Cover Lifting Height: ≥950mm
High Light:

Aluminium Liquid Degassing System

,

Graphite Rotor Online Liquid Degassing System

,

Aluminium Billet Casting Degassing Machine

Product Description:

The Aluminum Degassing Machine is designed for degassing aluminium foundry. It has a digital display for temperature control, total power of 45 kW, vacuum pump of 2X-70A, rotary speed of 0-600r/min and a degassing box with a static capacity of 700kg for aluminium alloy degassing liquid. This machine is an inline rotary degassing unit, ideal for aluminum casting foundries.

The Aluminum Degassing Machine is designed to be highly efficient in removing impurities such as hydrogen, oxygen and nitrogen from molten aluminium. The degassing process is carried out by injecting inert gas into the molten metal, increasing its degassing efficiency. The machine also provides high accuracy and stability in temperature control, ensuring precise results.

The Aluminum Degassing Machine is highly efficient and cost-effective for aluminium alloy degassing liquid. It is extremely user-friendly and easy to maintain, with low operating costs. This machine is designed to provide quality degassing results and maximum efficiency for aluminium casting foundries.



Features:

  • Product Name: Aluminum Degassing Machine
  • Static aluminum liquid capacity of degassing box kg: 700
  • Power Voltage V: 380±10%
  • Frequency Hz: 50
  • Box Cover Lifting Height: ≥950mm
  • Temperature Control: Digital Display
  • Aluminum Alloy Refining And Degassing
  • Aluminum Degassing Rotor Product
  • Aluminium Alloy Degassing Liquid Machine


Technical Parameters:

Parameter Value
Vacuum Degree ≤-0.092MPa
Rated molten aluminum flow rate t/h 10
Total Power kW KW < 45
Frequency Hz 50
Rotor speed r/min 0~600
Box Cover Lifting Height ≥950mm
Static aluminum liquid capacity of degassing box kg 700
Temperature Control Digital Display
Power Voltage V 380±10%
Weight 200KG
Degassing Rotor Aluminum Yes
Degassing Aluminium Foundry Yes
Aluminium Alloy Degassing Product Yes


Applications:

HYDEB HD-2xxx aluminum degassing machine is designed for aluminum foundry degassing process, and suitable for online degassing liquid system. It is equipped with graphite degassing rotor and shaft, vacuum degassing, and rated molten aluminum flow rate of 10 t/h. The rotor speed can be adjusted from 0 to 600r/min and the frequency is 50Hz. It is with digital display temperature control, making sure the degassing process is accurate and efficient.

This aluminum degassing machine is mainly used in aluminum foundries, helping to create high quality, clean and efficient aluminum products. It can effectively remove entrapped gases and other impurities from the liquid aluminum, and maximize the quality of the molten aluminum. The machine is equipped with an advanced temperature control system, providing precise temperature control and ensuring the stability of the degassing process. It is also equipped with a vacuum pump to ensure the degassing process is fast and efficient.

HYDEB HD-2xxx aluminum degassing machine is an ideal choice for any aluminum foundry, providing a safe and reliable degassing process. It is highly efficient and durable, ensuring a stable and reliable production process. The machine is also easy to operate and maintain, making it an ideal choice for any aluminum foundry.



Customization:

Customize your Aluminum Degassing Machine with HYDEB
  • Brand Name: HYDEB
  • Model Number: HD-2xxx
  • Place of Origin: Jinan, China
  • Power Voltage V: 380±10%
  • Rotor speed r/min: 0~600
  • Box Cover Lifting Height: ≥950mm
  • Static aluminum liquid capacity of degassing box kg: 700
  • Vacuum Pump: 2X-70A

HYDEB is the best choice for your Degassing Liquid Machine, Degasser Alumina Product, Aluminum Foundry Degasser, Alloy Degassing needs.

Graphite Rotor Online Liquid Degassing System For Aluminium Billet Casting Machine 0

FAQ:

FAQ

Q1: What is the brand name of Aluminum Degassing Machine?
A1: The brand name of Aluminum Degassing Machine is HYDEB.

Q2: What is the model number of Aluminum Degassing Machine?
A2: The model number of Aluminum Degassing Machine is HD-2xxx.

Q3: Where is Aluminum Degassing Machine made?
A3: Aluminum Degassing Machine is made in Jinan, China.

Q4: What is the purpose of Aluminum Degassing Machine?
A4: Aluminum Degassing Machine is mainly used to remove the gas generated in the aluminum liquid during melting and casting.

Q5: What are the features of Aluminum Degassing Machine?
A5: The features of Aluminum Degassing Machine include high efficiency, low energy consumption, automatic operation, safe and reliable operation, etc.
