Inline Rotary Degassing Liquid Unit Equipment For Aluminium Casting

Inline Rotary Degassing Liquid Unit Equipment For Aluminium Casting
Inline Rotary Degassing Liquid Unit Equipment For Aluminium Casting Inline Rotary Degassing Liquid Unit Equipment For Aluminium Casting Inline Rotary Degassing Liquid Unit Equipment For Aluminium Casting Inline Rotary Degassing Liquid Unit Equipment For Aluminium Casting Inline Rotary Degassing Liquid Unit Equipment For Aluminium Casting Inline Rotary Degassing Liquid Unit Equipment For Aluminium Casting Inline Rotary Degassing Liquid Unit Equipment For Aluminium Casting Inline Rotary Degassing Liquid Unit Equipment For Aluminium Casting Inline Rotary Degassing Liquid Unit Equipment For Aluminium Casting

Large Image :  Inline Rotary Degassing Liquid Unit Equipment For Aluminium Casting

Product Details:
Place of Origin: Jinan, China
Brand Name: HYDEB
Certification: CE ISO9001
Model Number: HD-2xxx
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: 32000USD/set
Packaging Details: Standard exporting package
Delivery Time: 45 workdays
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 60 sets per year

Inline Rotary Degassing Liquid Unit Equipment For Aluminium Casting

Description
Rotor Speed R/min: 0~600 Power Phase: 3
Frequency Hz: 50 Vacuum Degree: ≤-0.092MPa
Total Power KW: KW < 45 Weight: 200KG
Static Aluminum Liquid Capacity Of Degassing Box Kg: 700 Power Voltage V: 380±10%
High Light:

Aluminium Casting Inline Rotary Degasser

,

Rotary Degassing Liquid Unit

,

Aluminum Degassing Liquid Equipment

Product Description:

The Aluminum Degassing Machine is an advanced inline degassing unit designed to efficiently remove hydrogen and other gases from molten aluminum. The machine is equipped with a graphite degassing rotor and shaft, as well as a high-quality degassing rotor aluminum that ensures maximum efficiency during degassing. It offers a weight of 200KG, rotors speed ranging from 0~600r/min, a frequency of 50Hz, and a power phase of 3. It also comes with a box cover lifting height of 950mm or more, making it a reliable and effective degassing machine.



Features:

  • Product Name: Aluminum Degassing Machine
  • Inline Degassing, Industrial Nitrogen Degassing Machine, Inline Degassing Machine
  • Inlet molten aluminum temperature ℃: 700
  • Weight: 200KG
  • Frequency Hz: 50
  • Rated molten aluminum flow rate t/h: 10
  • Temperature Control: Digital Display


Technical Parameters:

Parameter Value
Inlet molten aluminum temperature(℃) 700
Box Cover Lifting Height(mm) ≥950
Frequency(Hz) 50
Vacuum Pump 2X-70A
Static aluminum liquid capacity of degassing box(kg) 700
Rotor speed(r/min) 0~600
Rated molten aluminum flow rate(t/h) 10
Total Power(KW) 45
Power Phase 3
Weight(KG) 200
Type Inline Rotary Degassing Unit Casting, Degassing Liquid Machine, Degassing Aluminium Foundry


Applications:

  • The HYDEB HD-2xxx Aluminum Degassing Machine is a powerful degassing liquid machine designed to degas molten aluminum ingots. It is ideal for use in the aluminum alloy industry, providing the highest efficiency and reliability.
  • Equipped with a total power of 45kW, it has a static aluminum liquid capacity of 700kg and operates at a frequency of 50Hz. Inlet molten aluminum temperature is up to 700℃ and the machine weighs 200kg.
  • The HYDEB HD-2xxx Aluminum Degassing Machine is an ideal choice for molten ingot degassing, making it the perfect choice for the aluminum alloy industry. It is highly reliable and efficient, and is made in Jinan, China.


Customization:

HYDEB Customize Aluminum Degassing Machine, Model HD-2xxx:

  • Brand Name: HYDEB
  • Model Number: HD-2xxx
  • Place of Origin: Jinan, China
  • Total Power kW: KW < 45
  • Rotor speed r/min: 0~600
  • Static aluminum liquid capacity of degassing box kg: 700
  • Box Cover Lifting Height: ≥950mm
  • Temperature Control: Digital Display
  • Keywords: Inline Rotary Degassing Unit Casting, Graphite Degassing Rotor And Shaft, Double Layer Refractory Lined Furnace, High Vacuum Degassing System
  • Inline Rotary Degassing Liquid Unit Equipment For Aluminium Casting 0


FAQ:

Q1: What is the Brand Name of the Aluminum Degassing Machine?
A1: The Brand Name of the Aluminum Degassing Machine is HYDEB.
Q2: What is the Model Number of the Aluminum Degassing Machine?
A2: The Model Number of the Aluminum Degassing Machine is HD-2xxx.
Q3: Where is the Aluminum Degassing Machine from?
A3: The Aluminum Degassing Machine is from Jinan, China.
Q4: How to operate the Aluminum Degassing Machine?
A4: Please refer to the user manual for the detailed operating instructions.
Q5: What kind of power does the Aluminum Degassing Machine need?
A5: The Aluminum Degassing Machine needs 220V/380V power, 50Hz frequency.
