Rotary Aluminum Molten Liquid Degasser Machine Launder Out Shell 40% Degassing Efficiency

Certification
China Jinan Hydeb Thermal Tech Co., Ltd. certification
China Jinan Hydeb Thermal Tech Co., Ltd. certification
I'm Online Chat Now

Rotary Aluminum Molten Liquid Degasser Machine Launder Out Shell 40% Degassing Efficiency

Rotary Aluminum Molten Liquid Degasser Machine Launder Out Shell 40% Degassing Efficiency
Rotary Aluminum Molten Liquid Degasser Machine Launder Out Shell 40% Degassing Efficiency Rotary Aluminum Molten Liquid Degasser Machine Launder Out Shell 40% Degassing Efficiency Rotary Aluminum Molten Liquid Degasser Machine Launder Out Shell 40% Degassing Efficiency Rotary Aluminum Molten Liquid Degasser Machine Launder Out Shell 40% Degassing Efficiency Rotary Aluminum Molten Liquid Degasser Machine Launder Out Shell 40% Degassing Efficiency

Large Image :  Rotary Aluminum Molten Liquid Degasser Machine Launder Out Shell 40% Degassing Efficiency

Product Details:
Place of Origin: Jinan, China
Brand Name: HYDEB
Certification: CE ISO9001
Model Number: HDR-2
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: 1000USD/set
Packaging Details: Standard exporting package
Delivery Time: 45 workdays
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 60 sets per year

Rotary Aluminum Molten Liquid Degasser Machine Launder Out Shell 40% Degassing Efficiency

Description
Launder Out Shell Surface Temperature: ≤60℃ Maximum Liquid Aluminum Temperature: 750℃
Degassing Efficiency: ≥40% Inert Gas: High-purity N2;High-purity Ar
Launder Lining Life: ≥18 Months Rotor Speed: 100-600rpm
High Light:

Launder Out Shell Aluminum Degassing Machine

,

Rotary Liquid Degasser Machine

,

Aluminum Molten Degasser Machine

Product Description:

The High Efficient Aluminium Purification Return Launder Type In-line Rotory Degassing Unit (LDU) is built to offer a higher degassing success rate. It features degassing rotors installed between the melting furnace and casting machine, in the similar direction of the launder. Plus, it further acquires a degassing region composed of some parts for multilevel in-line degassing. The number of rotors used in the operation depends on the volume of molten aluminium. To purify the molten metal, degassing agents such as Mg, Al, Ca are brought into contact with inert gas such as argon and nitrogen.



Features:

High degassing efficiency, above 40% makes it attractive to all potential users. Adopting multi-zone continuous degassing increases the contact surface and contact time between bubbles and molten aluminum, while the sealed design maintains an inert headspace above the molten aluminum surface during the entire casting period, preventing more slag to eliminate secondary pollution and improve degassing efficiency.

Low use cost and maintenance frequency make it economic and reliable. The molten aluminum heating and holding system is removed, reducing consumption. Launders are adopted for degassing, reducing the residual amount of molten aluminum and the loss of metal, and also offers low maintenance cost, convenient and fast replacement of launders.

Easy to install, this system is space-saving with small size and low weight. It does not require any structures or foundation to be installed, therefore a short period of time is required for on-site commissioning, reducing production downtime.

Convenient for alloy conversion, it does not have any heating device or deep box, so at the end of per casting most degassed metal can be made into a product, eliminating the residual aluminum liquid in the degassing tank and offering a rapid alloy Conversion.

In addition, this casting technology is easy to operate with no special starting procedure, a simple molten aluminum drainage device and simple working conditions. It is especially suitable for semi-continuous casting lines for the production of cast rods and renewable aluminum ingots.



Technical Parameters:

Items:

Parameters:

The maximum temperature of molten aluminum is 750℃. The launder shell surface temperature should not exceed 60℃. The service launder lining life is expected to be no less than 12 months. The speed of the rotor should be between 100-600 revolutions per minute (rpm). High-purity nitrogen (N2) and argon (Ar) are used as the inert gases. The degassing efficiency at the inlet hydrogen content not greater than the maximum flow rate should be ≤0.30ml/100gAl, and when the aluminum liquid is between 700-740 ℃, the hydrogen content after degassing should be ≤0.22ml/100g. The degassing efficiency when the inlet hydrogen content is greater than 0.30ml/100g-Al is expected to be greater than 35%. Lastly, the power supply should be 380V AC 50Hz, ≤10KVA.

Rotary Aluminum Molten Liquid Degasser Machine Launder Out Shell 40% Degassing Efficiency 0



Applications:

Heat Treatment Furnace from HYDEB is a leading Rotary Molten Aluminum Liquid Degasser Machine with graphite rotor. It is designed to be highly efficient with its rotor system that rotates between 100-600rpm, and its degassing efficiency reaching up to 40%. Its launder lining life is up to 18 months and launder out shell surface temperature is maintained at a maximum of 60℃. Furthermore, its heating system is able to keep the maximum liquid aluminum temperature at 750℃. HYDEB HDR-2 also comes with a circulating pump, bearing and bearing block for superior performance.



Customization:

Heat Treatment Furnace
Brand Name: HYDEB
Model Number: HDR-2
Place of Origin: Jinan, China
Rotor Speed: 100-600rpm
Launder Out Shell Surface Temperature: ≤60℃
Launder Lining Life: ≥18 Months
Degassing Efficiency: ≥40%
Maximum Liquid Aluminum Temperature: 750℃

Our Heat Treatment Furnace is equipped with online degassing, degasser box and other features that give it high degassing efficiency and excellent performance.



Support and Services:

We provide technical support and service for Heat Treatment Furnace. Our experts are on hand to answer any questions you have, answer any of your queries and provide support. We also provide maintenance services for our products, and can provide spare parts and accessories as needed.

Our technical support team is available by phone, email, or live chat, so you can get the help you need, when you need it. We also have an online knowledge base and FAQs for easy access to answers to common questions.

We guarantee a quick response time, and fast turn-around on repairs and maintenance. Our customer service team is available to help you with any issues you may have.
