15T Rectangular Melting Furnace +10% 2 Rated Aluminium Liquid Pouring Amount

15T Rectangular Melting Furnace +10% 2 Rated Aluminium Liquid Pouring Amount
15T Rectangular Melting Furnace +10% 2 Rated Aluminium Liquid Pouring Amount 15T Rectangular Melting Furnace +10% 2 Rated Aluminium Liquid Pouring Amount 15T Rectangular Melting Furnace +10% 2 Rated Aluminium Liquid Pouring Amount 15T Rectangular Melting Furnace +10% 2 Rated Aluminium Liquid Pouring Amount 15T Rectangular Melting Furnace +10% 2 Rated Aluminium Liquid Pouring Amount 15T Rectangular Melting Furnace +10% 2 Rated Aluminium Liquid Pouring Amount

Large Image :  15T Rectangular Melting Furnace +10% 2 Rated Aluminium Liquid Pouring Amount

Product Details:
Place of Origin: Jinan, China
Brand Name: hydeb
Certification: CE ISO9001
Model Number: HBQ-213
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: 8000USD/set
Packaging Details: Standard exporting package
Delivery Time: 45 workdays
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 60 sets per year

15T Rectangular Melting Furnace +10% 2 Rated Aluminium Liquid Pouring Amount

Description
Feature: Energy-saving Application: Melting Aluminum
Melting Capacity: Melting Capacity Power Consumption: 400KWH/T
Furnace Temperature Uniformity: 5 Celsius Degree Temperature Control: PID+SSR Automatic Temperature Control
High Light:

rectangular melting furnace

,

Melting Aluminum Crucible Furnace

,

15T melting furnace

No Item 15T rectangular melting furnace 1 Max. volume 15T +10% 2 Rated aluminium liquid pouring amount 15T 3

Hot sales Aluminum Alloy Casting Melting and Holding Crucible Furnace



used for melting and holding of aluminum alloy. Suitable for such process as metal casting, pouring, degassing and slag before die forging of liquid, preparing alloy, homogeneous structure, and adjusting temperature.

Crucible capacity: 10-3000kg (AL)

Energy: Electricity, gas

Crucible: graphite, casting iron, casting steel



No Item 15T rectangular melting furnace
1 Max. volume 15T +10%
2 Rated aluminium liquid pouring amount 15T
3 Melting pool depth (to the furnace door) 650+100 mm
4 Furnace door working mode Chain transmission, electric lifting, deadweight and compression
5 Furnace door size 2000x1000 mm
6 Furnace chamber rated working temperature ≤1100℃
7 Furnace wall temperature increase ≤65℃
8 Burner type Heat accumulating type CT300+300
9 Furnace natural gas pressure 0.008-0.02 Mpa adjustable
10 Max. Gas consumption 350Nm3/h
11 Melting rate gas consumption/cube/ton (raw material is 95% above waste aluminium) 65 cube below
12 Smoke temperature ≤200℃ (melting)



15T Rectangular Melting Furnace +10% 2 Rated Aluminium Liquid Pouring Amount 015T Rectangular Melting Furnace +10% 2 Rated Aluminium Liquid Pouring Amount 1
