Long Distance Molten Aluminum Transfer Ladle Recycled Aluminum Equipment

Large Image : Long Distance Molten Aluminum Transfer Ladle Recycled Aluminum Equipment

Product Details:

Place of Origin:	Jinan, China
Brand Name:	HYDEB
Certification:	CE ISO9001
Model Number:	HBQ-256

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	16000USD/set
Packaging Details:	Standard exporting package
Delivery Time:	45 workdays
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	60 sets per year

Contact Now

Long Distance Molten Aluminum Transfer Ladle Recycled Aluminum Equipment

Description

Power (kW):	Power (kW):	Product Name:	Molten Aluminum Transfer Ladle
Molten Aluminum Transfer Ladle:	More Than 90 KM	Capacity:	500-5000KG Or Customized
Natural Temperature Drop:	Less Than 10 ℃/h	Weight (T):	T
Highlight:	Recycled Aluminum Transfer Ladle , 90KM Molten Aluminum Transfer Ladle , Long Distance Aluminum Transfer Ladle

Long-distance molten aluminum transfer ladle Recycled Aluminum Equipment

Long-distance molten aluminum transfer ladle Recycled Aluminum

Equipment Introduction

• The molten aluminum transfer ladle is mostly used for long-distance safe transportation of molten aluminum to an aluminum

casting factory.

Equipment Features

• No molten aluminum leakage, high transportation safety. The ladle body is firm; the ladle lip and cover are reliably sealed,

with molten aluminum not to overflow even if the ladle body topples over.

• Excellent thermal insulation performance, low natural temperature drop. The thermal insulation layer, made of a heat-insulating

Nano-fibrous material, has excellent thermal insulation performance; made of a special material and specially structured, the

working layer (in contact with the molten aluminum) prevents the molten aluminum from leaking. The ladle has low surface

temperature, suitable for long-distance transportation.

• Low weight, transportation cost-saving. The lightweight heat-insulating Nano-material ensures a small ladle body size and a low

ladle body weight.

• Excellent non-stickiness with molten aluminum, easy to clean. The inner layer of the lining, made of a dedicated refractory

casting material, has good aluminum tolerance and high resistance to corrosion by molten aluminum.

• High resistance to thermal and cold shocks, high strength. The dedicated high-strength ladle lining can resist frequent thermal

shocks without falling off.

• A long service life. Professionally designed and manufactured, ensuring that the lining life is more than 24 months in

continuous use.

• The lade cover actuator (optional) helps to open the ladle cover with ease.


			Items
			Parameters
			Remarks

			Modle
			HBQ-230

			Heating Type
			Small; Medium; Big

			Max. Burning Calorific Value
			20x104 Kcal/h

			Max Heating Temperature
			1100℃

			Working Heating Temperature
			0-850℃

			Heating Rate
			0-50 ℃/min Adjustable

			Time to Reach Temperature
			0-60 min

			Heating Temperature Uniformity
			≤50 ℃

			Lifting Power
			Air Cylinder Driver

			Lifting Stroke
			0-400mm

			Gas
			Gas Type
			Natural Gas

			Gas Pressure
			5000 ±5% Pa

			Gas Flow
			≤24 m³/h

			Power
			Voltage
			380 V, 3P

			Frequency
			50HZ

			Rated Power
			3 KW

			Compressed Air
			Pressure
			0.5-0.7 MPa

			Flow
			≤50 M3/H

Tag:

700KG Aluminum Holding Furnace,

1500KG Aluminum Holding Furnace,

Aluminum Holding Furnace For melting liquid

Contact Details

Jinan Hydeb Thermal Tech Co., Ltd.

Contact Person: Miss. Ally Qin

Tel: +8617862974932

Fax: 86-531-88969137
