5000kgs Regenerative Melting Holding Crucible Furnace For Aluminum Ingot

Certification
China Jinan Hydeb Thermal Tech Co., Ltd. certification
China Jinan Hydeb Thermal Tech Co., Ltd. certification
I'm Online Chat Now

5000kgs Regenerative Melting Holding Crucible Furnace For Aluminum Ingot

5000kgs Regenerative Melting Holding Crucible Furnace For Aluminum Ingot
5000kgs Regenerative Melting Holding Crucible Furnace For Aluminum Ingot 5000kgs Regenerative Melting Holding Crucible Furnace For Aluminum Ingot 5000kgs Regenerative Melting Holding Crucible Furnace For Aluminum Ingot 5000kgs Regenerative Melting Holding Crucible Furnace For Aluminum Ingot 5000kgs Regenerative Melting Holding Crucible Furnace For Aluminum Ingot

Large Image :  5000kgs Regenerative Melting Holding Crucible Furnace For Aluminum Ingot

Product Details:
Place of Origin: Jinan, China
Brand Name: HYDEB
Certification: CE ISO9001
Model Number: HBQ-231
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: 1000USD/set
Packaging Details: Standard exporting package
Delivery Time: 45 workdays
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100 sets per year

5000kgs Regenerative Melting Holding Crucible Furnace For Aluminum Ingot

Description
Material: Natural Gas Burner, Steel Color: According To Your Requirment
Ladle Cover: Customized Usage: Aluminun Melting Holding
Capacity: 200kg~5000kg Melting Material: Aluminium Ect
High Light:

5000kgs Crucible Furnace

,

Regenerative Melting Holding Crucible Furnace

,

Crucible Furnace For Aluminum Ingot

5000kgs Regenerative Melting Holding Crucible Furnace For Aluminum Ingot

15000kgs Regenerative Gas Fired Melting Holding Crucible Furnace For Aluminum Ingot



Mainly used for maintaining temperature of molten aluminum alloys, suitable for all the crafting processes, such as pre-aluminum casting degassing, alloy preparation, uniform structure and temperature regulation and so on.

• Energy source can be electricity and gas.



FEATURES

•Higher-quality molten aluminum can be obtained. Molten aluminum temperature accuracy, composition uniformity and less hydrogen content can be guaranteed.
• Flexible production organization. The crucible can be replaced at any time for production of different types of alloys, without contaminating the molten aluminum.
• Low burning loss of aluminum. The aluminum in the crucible is heated with heat conduction of the crucible, without local high temperature, reducing oxidizing loss and high-temperature volatilization, lowering the burning loss of aluminum to a level below 1.2%.
• The furnace floor is molded by monolithic casting with a casting material. Moreover, at the bottom of the furnace is a leakage outlet, through which the molten aluminum can outflow once the crucible is broken, reducing the risk of damage to the furnace body.
• The temperature of the furnace chamber and molten aluminum is controlled by series circuit, ensuring sufficient heating efficiency and preventing overheating of the furnace chamber.

• The molten aluminum thermocouple protect tube is made from silicon nitride, which is well heat-conducting, resistant to corrosion by the molten aluminum, resistant to thermal and cold shocks and highly strong. The tube can be directly immersed in the molten aluminum to measure its temperature. It has a service life of more than 2 years.

• Multiple safety protection modes are adopted, such as molten aluminum over-temperature alarm, furnace chamber over-temperature alarm and crucible leakage alarm and so on.





SN Items Data Remarks
1 Efficient furnace capacity kg (Al) 510
2 Melting Rate kg/h (Al) 450 Inside the crucible there is already have 1/3 molten aluminum.
3 Burner TGB
4 Energy Consumption m3/h Around 40
5 Maximum furnace temperature ℃ 950
6 Precision of molten aluminum temperature control ℃ ≤± 5
7 Temperature control mode PID+Dual temperature control
8 Crucible type and size mm

ODΦ880,

Height 1170

TBN1100

Morgen

9 Furnace surface temperature rise ℃ ≤50 Except for the installation site of the heating tube, the discharge outlet and rising tube
10 Gas Source Gas type Natural Gas
Gas pressure 5 Kpa
Max. Flow 75 m3/h
11 Power Source Voltage V 380
Frequency HZ 50
Power Kw ≤5
12 Air Pressure MPa 0.5-0.7



5000kgs Regenerative Melting Holding Crucible Furnace For Aluminum Ingot 05000kgs Regenerative Melting Holding Crucible Furnace For Aluminum Ingot 15000kgs Regenerative Melting Holding Crucible Furnace For Aluminum Ingot 25000kgs Regenerative Melting Holding Crucible Furnace For Aluminum Ingot 35000kgs Regenerative Melting Holding Crucible Furnace For Aluminum Ingot 45000kgs Regenerative Melting Holding Crucible Furnace For Aluminum Ingot 5
