Graphite Rotor Speed 0-600 R/min Aluminum Degassing Machine With Frequency Conversion Adjustment And High Power Wire Diameter

Product Description:

The Rotary Degassing Unit is a crucial aluminum In-Furnace Impurity Removal Equipment designed to enhance the refining process in the aluminum industry. This advanced aluminum Refining degassing machine is equipped with a high-performance graphite rotor that allows for precise control of the refining parameters.

Key Features:

• Graphite rotor speed r/min: Frequency Conversion Adjustment 0-600
• Total Power kW: 3kW
• Refined Gas Pressure MPa: Adjustable From 0.1 To 0.6
• Refined Gas Flow Rate L/min: Adjustable From 15 To 30
• Refined flux powder spraying amount g/min: 0～350

The graphite rotor speed of the Rotary Degassing Unit can be easily adjusted within the range of 0 to 600 revolutions per minute, allowing for precise control over the degassing process. With a total power of 3kW, this machine delivers reliable performance while maintaining energy efficiency.

One of the standout features of this aluminum In-Furnace Slag Removal Equipment is its adjustable refined gas pressure, which can be set anywhere between 0.1 to 0.6 MPa. This flexibility ensures that the degassing unit can adapt to varying production requirements and provide consistent results.

Moreover, the refined gas flow rate of the machine is adjustable from 15 to 30 liters per minute, offering operators the ability to fine-tune the degassing process according to specific needs. Additionally, the refined flux powder spraying amount can range from 0 to 350 grams per minute, allowing for precise control over the refining agents used.

Overall, the Rotary Degassing Unit is a reliable and efficient solution for aluminum refining processes, offering precise control over key parameters to ensure the production of high-quality aluminum products. Whether you are looking to remove impurities, degas the molten metal, or eliminate slag from the furnace, this machine provides the performance and flexibility required for a successful aluminum refining operation.

Features:

• Product Name: Rotary Degassing Unit
• Graphite rotor speed r/min: Frequency Conversion Adjustment 0-600
• Refined Gas Purity %: ≥99.996
• Net weight: 1200kg
• Refined flux powder spraying amount g/min: 0～350
• Power wire diameter mm2: ≥2.5

Technical Parameters:

Applications:

The HYDEB Rotary Degassing Unit model XC210A(-1) is a versatile piece of equipment designed for various product application occasions and scenarios. This furnace side refining equipment plays a crucial role in the aluminum industry, particularly in the degassing and refining processes.

One of the primary application scenarios for the XC210A(-1) Rotary Degassing Unit is in aluminum foundries and smelting facilities. This machine effectively removes hydrogen and other impurities from molten aluminum, ensuring high-quality final products. Its capability as an aluminum degassing machine makes it an indispensable tool for maintaining the desired metal purity levels.

Another key application occasion for this equipment is in aluminum In-Furnace Slag Removal. By utilizing the Rotary Degassing Unit, operators can efficiently remove slag and dross from the molten metal, improving the overall cleanliness and quality of the aluminum being produced.

Manufactured in Jinan, China, this product boasts CE and ISO9001 certifications, guaranteeing its quality and reliability. With a minimum order quantity of 1 set and a price of 12000USD/set, the XC210A(-1) is accessible to both small-scale operations and larger industrial facilities.

The packaging details include standard exporting packages, ensuring safe and secure delivery to customers worldwide. The delivery time of 45 workdays, along with flexible payment terms such as L/C and T/T, makes acquiring this equipment convenient and hassle-free.

With a supply ability of 500 units per year, the HYDEB Rotary Degassing Unit model XC210A(-1) is readily available to meet the demands of various aluminum production facilities. Its specifications, including a frequency of 50Hz, three-phase four-wire power supply, adjustable refined gas pressure from 0.1 to 0.6 MPa, power wire diameter of ≥2.5 mm2, and refined gas flow rate adjustable from 15 to 30 L/min, make it a versatile and efficient solution for diverse applications in the industry.

Customization:

Product Customization Services for the Rotary Degassing Unit:

- Brand Name: HYDEB

- Model Number: XC210A(-1)

- Place of Origin: Jinan, China

- Certification: CE ISO9001

- Minimum Order Quantity: 1 set

- Price: 12000USD/set

- Packaging Details: Standard exporting package

- Delivery Time: 45 workdays

- Payment Terms: L/C, T/T

- Supply Ability: 500 units per year

- Power Supply Phases: Three-phase Four-wire

- Graphite rotor speed r/min: Frequency Conversion Adjustment 0-600

- Refined Gas Purity %: ≥99.996

- Refining flux particle size mm: ≤5

- Frequency Hz: 50Hz

Keywords: Furnace side refining equipment, Aluminum degassing machine, aluminum Furnace side refining equipment

Support and Services:

The Rotary Degassing Unit product comes with comprehensive technical support and services to ensure optimal performance and customer satisfaction. Our team of experts is available to assist with installation, troubleshooting, and maintenance to keep your unit running smoothly. Additionally, we offer training programs to help users maximize the efficiency and effectiveness of the degassing unit. Our goal is to provide top-notch support to ensure your success with our product.
