Rotary Degasser For Molten Aluminum / Rotary Aluminum Liquid Degassing Machine

Certification
China Jinan Hydeb Thermal Tech Co., Ltd. certification
China Jinan Hydeb Thermal Tech Co., Ltd. certification
I'm Online Chat Now

Rotary Degasser For Molten Aluminum / Rotary Aluminum Liquid Degassing Machine

Rotary Degasser For Molten Aluminum / Rotary Aluminum Liquid Degassing Machine
Rotary Degasser For Molten Aluminum / Rotary Aluminum Liquid Degassing Machine Rotary Degasser For Molten Aluminum / Rotary Aluminum Liquid Degassing Machine Rotary Degasser For Molten Aluminum / Rotary Aluminum Liquid Degassing Machine Rotary Degasser For Molten Aluminum / Rotary Aluminum Liquid Degassing Machine

Large Image :  Rotary Degasser For Molten Aluminum / Rotary Aluminum Liquid Degassing Machine

Product Details:
Place of Origin: Jinan, China
Brand Name: HYDEB
Certification: CE ISO9001
Model Number: HDR-2xxx
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: 9998USD/set
Packaging Details: Standard exporting package
Delivery Time: 45 workdays
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 60 sets per year

Rotary Degasser For Molten Aluminum / Rotary Aluminum Liquid Degassing Machine

Description
Refined Gas Purity %: ≥99.997 Rotor Swing Range: 30°
Frequency Hz: 50Hz Refined Gas Flow Rate M³/h: Adjustable From 5.7 To 25.5
Refinement And Degassing Time Min: 0 To 99 Total Power KW: <150kW
Power Supply Phases: Three-phase Four-wire Refined Gas Pressure MPa: Adjustable From 0.1 To 0.6
High Light:

Rotary Degasser For Molten Aluminum

,

Rotary Aluminum Liquid Degassing Device

,

Rotary Molten Aluminum Degassing Machine

Product Description:

The Rotary Degassing Unit is an aluminum furnace side refining equipment, designed to help aluminum smelters improve their in-furnace slag removal efficiency. This unit offers a total power of up to 150kW and features a graphite rotor with a swing range of 30° and a speed ranging from 100 to 400 r/min. The rotor tilt range is 0 to 32°, and the voltage of this unit is 380V. It is an ideal refining equipment for aluminum smelters to apply in front of the furnace, helping them increase the efficiency of their aluminum In-Furnace Slag Removal Equipment.



Features:

  • Product Name: Rotary Degassing Unit
  • Total Power kW: <150kW
  • Rotor Swing Range: 30°
  • Graphite Rotor Speed r/min: 100-400
  • Refined Gas Purity %: ≥99.997
  • Voltage V: 380V
  • Furnace side refining equipment
  • Molten Aluminum degassing machine
  • Aluminum Furnace side refining equipment


Technical Parameters:

Parameter Value
Refined Gas Flow Rate m³/h Adjustable From 5.7 To 25.5
Refinement and Degassing Time min 0 To 99
Total Power kW <150kW
Refined Gas Purity % ≥99.997
Graphite Rotor Speed r/min 100-400
Voltage V 380V
Frequency Hz 50Hz
Rotor Swing Range 30°
Power Supply Phases Three-phase Four-wire
Rotor Tilt Range mm 0 To 32°



Rotary Degasser For Molten Aluminum / Rotary Aluminum Liquid Degassing Machine 0

Applications:

HYDEB HDR-2xxx rotary degassing unit is a smelting purification equipment which is designed for furnace side refining. It is a type of aluminum refining degassing machine which helps to refine and degas molten aluminum alloy. This Rotary Degassing Unit is certified with CE and ISO9001 and it is produced in Jinan, China. It has a minimum order quantity of 1 set and the price is 9998USD/set. The packaging details are standard exporting package and the delivery time is 45 workdays. The payment terms are L/C, T/T, Western Union, MoneyGram. It has a supply ability of 60 sets per year. It has a power supply phases of three-phase four-wire and a refined gas pressure MPa which is adjustable from 0.1 to 0.6. The rotor swing range is 30° and the refined gas purity is ≥ 99.997. The refinement and degassing time can be adjusted from 0 to 99 min. This Rotary Degassing Unit is a perfect choice for refining and degassing molten aluminum alloy with high efficiency and reliability.



Customization:

Customized Rotary Degassing Unit - HYDEB HDR-2xxx
  • Brand Name: HYDEB
  • Model Number: HDR-2xxx
  • Place of Origin: Jinan, China
  • Certification: CE ISO9001
  • Minimum Order Quantity: 1 set
  • Price: 9998USD/set
  • Packaging Details: Standard exporting package
  • Delivery Time: 45 workdays
  • Payment Terms: L/C, T/T, Western Union, MoneyGram
  • Supply Ability: 60 sets per year
  • Rotor Tilt Range mm: 0 To 32°
  • Rotor Swing Range: 30°
  • Refined Gas Purity %: ≥99.997
  • Refined Gas Pressure MPa: Adjustable From 0.1 To 0.6
  • Graphite Rotor Speed r/min: 100-400

The HYDEB HDR-2xxx Rotary Degassing Unit is an advanced aluminum Furnace side refining equipment, aluminum Refining degassing machine and molten Aluminum degassing machine which offers superior refining performance, reliable operation, and long service life.



Support and Services:

Our Rotary Degassing Unit provides technical support and service for customers. We offer detailed installation instructions, troubleshooting guides, and product maintenance tips to ensure you get the most out of your experience with our product. We also provide a live chat service and toll-free phone number for customers to get in touch with us directly. Our team of experts is available 24/7 to answer any questions or concerns you may have.



Packing and Shipping:

Packaging & Shipping for Rotary Degassing Unit:

The Rotary Degassing Unit shall be packaged in a strong, waterproof container. The components shall be wrapped separately in a bubble wrap or paper cushioning material. The packaging material shall be marked with the appropriate shipping information, including the weight, size, and product name.

The Rotary Degassing Unit shall be shipped in accordance with the delivery terms agreed by the buyer and seller. The unit must be shipped in a timely manner and in good condition.



FAQ:

Q&A about Rotary Degassing Unit
Q1: What is Rotary Degassing Unit?
A1: Rotary Degassing Unit is a kind of machinery used to degas molten aluminum, produced by HYDEB, model number is HDR-2xxx. Q2: Where is Rotary Degassing Unit produced?
A2: Rotary Degassing Unit is produced in Jinan, China. Q3: Does Rotary Degassing Unit have certification?
A3: Rotary Degassing Unit is certified with CE and ISO9001. Q4: What is the minimum order quantity of Rotary Degassing Unit?
A4: The minimum order quantity of Rotary Degassing Unit is 1 set. Q5: How much is the price of Rotary Degassing Unit?
A5: The price of Rotary Degassing Unit is 9998USD/set.
