Molten Aluminum Liquid Refining Degassing Machine Adjustable Speed Graphite Rotor

Molten Aluminum Liquid Refining Degassing Machine Adjustable Speed Graphite Rotor
Molten Aluminum Liquid Refining Degassing Machine Adjustable Speed Graphite Rotor Molten Aluminum Liquid Refining Degassing Machine Adjustable Speed Graphite Rotor Molten Aluminum Liquid Refining Degassing Machine Adjustable Speed Graphite Rotor Molten Aluminum Liquid Refining Degassing Machine Adjustable Speed Graphite Rotor Molten Aluminum Liquid Refining Degassing Machine Adjustable Speed Graphite Rotor

Large Image :  Molten Aluminum Liquid Refining Degassing Machine Adjustable Speed Graphite Rotor

Product Details:
Place of Origin: Jinan, China
Brand Name: HYDEB
Certification: CE ISO9001
Model Number: HDR-2xxx
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: 10000USD/set
Packaging Details: Standard exporting package
Delivery Time: 45 workdays
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 60 sets per year

Molten Aluminum Liquid Refining Degassing Machine Adjustable Speed Graphite Rotor

Description
Working Temperature: 0-80℃ Operation Mode: Automatic
Weight: 500KG Dimensions: 1000×1000×1500mm
Capacity: 500-1000 L/H Power Supply: 220V/50Hz
Pressure Range: 0.1-0.3MPa Product Name: Aluminum Rotary Degassing Unit
High Light:

Molten Aluminum Liquid Refining Degassing Machine

,

Adjustable Speed Graphite Rotor Rotary Degasser

,

Rotary Refining Equipment

Product Description:

The motor drives the graphite rotor immersed in the aluminum liquid to rotate, and at the same time, high-purity nitrogen (or argon) is introduced into the aluminum liquid through the graphite rotor. The rotor of the refiner can effectively break up the inert gas into small bubbles. The bubbles are evenly dispersed and floated in the molten aluminum. The hydrogen partial pressure in the molten aluminum is higher than that in the bubbles, and the hydrogen will diffuse into the inert gas and float to the liquid surface with the bubbles, thereby effectively reducing the hydrogen content in the molten aluminum.



Features:

● The bubbles are distributed in the whole melt, which increases the contact area between the refining bubbles and the metal melt, prolongs the gas contact reaction time with the harmful substances, and helps to remove the gas, slag and impurities dissolved in the metal melt out of the melt surface, the refining efficiency is high.



● The graphite rotor is made of high-purity graphite. The structure of the rotor not only breaks the bubbles, but also makes the aluminium melt and the refining gas ejected from the rotor evenly mixed, increasing the contact area and time between the bubbles and the aluminium alloy liquid, and improving the removal rate. Air purification effect.



● The combined purification process of "Gas + Flux" reduces the consumption of gas and refining agent, reduces the emission of flue gas, and improves the safety and environmental protection of the operating environment.

Technical Parameters:

Parameter Value
Product Name Rotary Degassing Unit
Application Aluminum Refining degassing, Molten Aluminum purification, Molten Aluminum degassing
Power Consumption 2.5KW
Pressure Range 0.1-0.3MPa
Capacity 500-1000 L/H
Working Temperature 0-80℃
Dimensions 1000×1000×1500mm
Control System PLC
Vacuum Degree ≤1Pa
Vacuum Pump Rotary Vane Pump
Material Stainless Steel
Weight 500KG


Applications:

HYDEB HDR-2xxx Aluminum Rotary Degassing Unit

HYDEB HDR-2xxx aluminum rotary degassing unit is a perfect refining equipment used in front of furnace. It is used for aluminum furnace side refining and degassing to remove the dissolved hydrogen gas and other impurities in the molten aluminum. This aluminum degassing machine is powered by 220V/50Hz and the noise level is below 70dB. It is equipped with a rotary vane pump to ensure the pressure range of 0.1-0.3MPa.

This aluminum rotary degassing unit is widely used in the aluminum extrusion, aluminum alloy material production, and aluminum die-casting industries. It can effectively remove hydrogen gas and other impurities from aluminum alloy materials, improve the quality of the products and reduce the production cost. Moreover, its advanced design ensures the degassing process is safe and efficient.

HYDEB HDR-2xxx aluminum rotary degassing unit is a reliable and efficient refining equipment for aluminum furnace side refining and degassing. It is an ideal solution to improve the quality of aluminum alloy materials and reduce the production cost.



Support and Services:

Technical Support and Service for Rotary Degassing Unit

We provide technical support and service for the Rotary Degassing Unit. Our highly trained technical team is available to answer any questions about the product, as well as provide troubleshooting and maintenance support.

We offer a comprehensive suite of services to assist in the installation, operation, and maintenance of the Rotary Degassing Unit. Our services include:

  • On-site installation and commissioning
  • Operational and maintenance training
  • Ongoing technical support
  • Spare parts supply
  • Equipment upgrades
  • Equipment repair and maintenance

We are committed to providing quality technical support and service for the Rotary Degassing Unit. Our team is dedicated to helping you maximize the performance and life of your equipment.



Molten Aluminum Liquid Refining Degassing Machine Adjustable Speed Graphite Rotor 0



FAQ:

Q1: What is a Rotary Degassing Unit?

A: Rotary Degassing Unit is a device produced by HYDEB, with model number HDR-2xxx, manufactured in Jinan, China. It is used for degassing and purifying liquids and gases.

Q2: What are the benefits of the Rotary Degassing Unit?

A: The Rotary Degassing Unit from HYDEB has the advantages of high efficiency, low energy consumption, easy operation and maintenance, and low noise level.

Q3: What type of liquids and gases can the Rotary Degassing Unit handle?

A: The Rotary Degassing Unit from HYDEB can handle liquids and gases of various viscosity, density, and temperature.

Q4: What is the operating temperature range of the Rotary Degassing Unit?

A: The Rotary Degassing Unit from HYDEB can operate within the temperature range of -50°C to 350°C.

Q5: Does the Rotary Degassing Unit require special maintenance?

A: The Rotary Degassing Unit from HYDEB is easy to maintain and requires no special maintenance.
