Return Launder Type Inline Rotary Degasser For Molten Aluminum

Certification
China Jinan Hydeb Thermal Tech Co., Ltd. certification
China Jinan Hydeb Thermal Tech Co., Ltd. certification
I'm Online Chat Now

Return Launder Type Inline Rotary Degasser For Molten Aluminum

Return Launder Type Inline Rotary Degasser For Molten Aluminum
Return Launder Type Inline Rotary Degasser For Molten Aluminum Return Launder Type Inline Rotary Degasser For Molten Aluminum Return Launder Type Inline Rotary Degasser For Molten Aluminum Return Launder Type Inline Rotary Degasser For Molten Aluminum Return Launder Type Inline Rotary Degasser For Molten Aluminum

Large Image :  Return Launder Type Inline Rotary Degasser For Molten Aluminum

Product Details:
Place of Origin: Jinan, China
Brand Name: HYDEB
Certification: CE ISO9001
Model Number: HDR-2
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: 1000USD/set
Packaging Details: Standard exporting package
Delivery Time: 45 workdays
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 60 sets per year

Return Launder Type Inline Rotary Degasser For Molten Aluminum

Description
Rotor Speed: 100-600rpm Inert Gas: High-purity N2;High-purity Ar
Launder Out Shell Surface Temperature: ≤60℃ Maximum Liquid Aluminum Temperature: 750℃
Launder Lining Life: ≥18 Months Degassing Efficiency: ≥40%
High Light:

Molten Aluminum Degassing Machine

,

Inline Rotary Degasser Machine

,

Return Launder Type Rotary Degasser

Product Description:

The High Efficient Aluminium Purification Return Launder Type In-line Rotory Degassing Unit (LDU) is designed with degassing rotors mounted between a melting furnace and casting machine to create a degassing zone divided into multiple parts for multiple-level in-line degassing. The number of rotors needed is determined by the flow rate of molten aluminum. This allows for higher degassing efficiency.



Features:

Bubble technology degassing has a high degassing efficiency, above 40%. It can achieve multi-zone continuous degassing, increasing the contact surface and contact time between bubbles and molten aluminum; with the sealed design,it can maintain an inert headspace above the molten aluminum surface during the entire casting period,preventing more slag and eliminating secondary pollution. In addition, the low use cost and maintenance frequency of this degassing process are advantageous. By removing the molten aluminum heating and holding system, consumption is reduced. Launders are adopted for degassing, cutting the residual amount of molten aluminum and the loss of metal, and the low maintenance cost and convenient and fast replacement of launders saves time.

Moreover, the installation of bubble degassing is also convenient; its small size and low weight offers space-savings and no structure or foundation is required to be installed. It can be installed in the joint positions of launders, offering a short period of time for on-site commissioning, thereby saving production downtime. Further convenience can be seen with the alloy conversion, as there is no heating device or deep box, meaning there is no need to eliminate the residual aluminum liquid in the degassing tank when changing the alloy. Operating bubble degassing is also very easy; it has no special starting procedure, a simple molten aluminum drainage device and convenient slag removal. Bubble technology degassing is especially suitable for semi-continuous casting lines for the production of cast rods and renewable aluminum ingots, as this casting technology features frequent alloy replacement.



Technical Parameters:

Items
  • Maximum temperature of molten aluminum: 750℃
  • Launder shell surface temperature: ≤60℃
  • Launder lining life: ≥12 months
  • Rotor speed: 100-600rpm
  • Inert gases: High-purity N2, high-purity Ar
  • Degassing efficiency: When it is not greater than the maximum flow rate, the inlet hydrogen content is ≤0.30ml/100gAl, when the aluminum liquid is 700-740℃, the hydrogen content after degassing is ≤0.22ml/100g. Degassing efficiency≥35% when hydrogen content at the inlet>0.30ml/100g-Al.
  • Power supply: 380V AC 50Hz, ≤10KVAReturn Launder Type Inline Rotary Degasser For Molten Aluminum 0


Applications:

HYDEB HDR-2 Heat Treatment Furnace is an in-line rotory degassing unit with an efficient rotor system. It is designed to meet the highest standards in the industry. The rotor speed is adjustable from 100 to 600rpm. The maximum liquid aluminum temperature that it can withstand is 750℃. The inert gas used in the furnace is high-purity N2 and high-purity Ar. The degassing efficiency of the furnace is ≥40%. The launder out shell surface temperature is ≤60℃. This heat treatment furnace is the perfect choice for any heat treatment process, and is capable of handling any job with precision and accuracy. It is the ideal solution for any heat treatment application.

Customization:

Customized Heat Treatment Furnace by HYDEB
Product Attributes
  • Brand Name: HYDEB
  • Model Number: HDR-2
  • Place of Origin: Jinan, China
  • Launder Out Shell Surface Temperature: ≤60℃
  • Launder Lining Life: ≥18 Months
  • Inert Gas: High-purity N2;High-purity Ar
  • Maximum Liquid Aluminum Temperature: 750℃
  • Degassing Efficiency: ≥40%
Key Features
  • Inline Rotary Degassing Unit
  • Launder to degas in molten aluminum
  • High-efficiency, environment-friendly degassing


Support and Services:

Technical Support and Service for Heat Treatment Furnace

Our company provides professional technical support and service for heat treatment furnace. Our service includes:

  • Proper installation and operation of furnace.
  • Regular maintenance and inspection of furnace.
  • Repair and replacement of furnace components if needed.
  • Troubleshooting of furnace issues.
  • Remote and on-site technical support.
  • Training of operators.

We are committed to providing our customers with the highest quality of products and services. If you have any questions or need assistance, please do not hesitate to contact us.
