500-1000 Kg/h Rotary Degassing Unit with Adjustable Time 1500℃

Large Image : 500-1000 Kg/h Rotary Degassing Unit with Adjustable Time 1500℃

Product Details:

Brand Name:	Hydeb
Certification:	ISO CE
Model Number:	BDU

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	＞30000USD
Packaging Details:	Wooden Box
Delivery Time:	50-60 Days
Payment Terms:	30%+70%
Supply Ability:	500 Sets Per Year

Contact Now

500-1000 Kg/h Rotary Degassing Unit with Adjustable Time 1500℃

Description

Capacity:	500-1000 Kg/h	Dimension:	1200mm X 800mm X 1500mm
Power Source:	Electric	Degassing Time:	Adjustable
Max Temperature:	1500℃	Max Pressure:	0.1MPa
Gas Inlet Pressure:	0.4-0.6 MPa	Total Power Kw:	<47
Highlight:	adjustable degassing time rotary unit , 500 kg capacity degassing unit , rotary degassing unit 1000 kg/h production

Adjustable Degassing Time and 500 Kg Capacity Rotary Degassing Unit for 500-1000 Kg/h Production

Product Overview

The Rotary Degassing Unit is essential equipment in metal casting, designed to effectively remove impurities from molten metal (1200mm × 800mm × 1500mm dimensions). Its adjustable degassing time allows precise process control, achieving 60% degassing efficiency for superior metal quality. Operating at 0.4-0.6 MPa gas inlet pressure with 500-1000 Kg/h capacity, this unit delivers consistent performance for medium to high-volume production.

Key Features

Adjustable degassing time for process optimization
High 60% degassing efficiency
500-1000 Kg/h production capacity
0.4-0.6 MPa gas inlet pressure range
Compact industrial design (1200mm × 800mm × 1500mm)
5 L/min cooling water consumption
380V/50Hz power supply
1500℃ maximum temperature capability

Technical Specifications

Parameter	Value
Degassing Efficiency	60%
Gas Consumption	10-15 L/min
Degassing Time	Adjustable
Gas Inlet Pressure	0.4-0.6 MPa
Maximum Pressure	0.1 MPa
Power Source	Electric
Capacity	500-1000 Kg/h
Maximum Temperature	1500℃
Gas Type	Argon

Applications

The Hydeb BDU In-line Rotary Degassing Unit is specifically designed for molten aluminum processing, with 60% degassing efficiency for hydrogen and impurity removal. Ideal for:

Aluminum foundries and die casting facilities
High-temperature aluminum processing (up to 1500℃)
Operations requiring precise degassing control
Medium to high-volume production environments

Customization Options

Model: BDU (ISO CE Certified)
Capacity: 500-1000 Kg/h
Weight: 500 Kg
Cooling Water: 5 L/min at 0.2-0.4 MPa
Packaging: Secure wooden box
Delivery: 50-60 days
Minimum Order: 1 unit (>$30,000 USD)

Technical Support & Services

Professional installation guidance
Comprehensive operator training
Technical troubleshooting assistance
Scheduled maintenance services
Performance upgrades and updates
