Variable Frequency Speed Regulation Rod Feeding Unit for Smooth Feeding of 8-13mm Rod Diameter

Product Description:

        ln casthouse applications, the control of grain size is absolutely essential in maintaining product consistency and quality,reducing costs, and maintaining high levels of productivity. The controlled addition of Aluminum’s titanium boron aluminium grain refiners to molten aluminium releases nucleant particles that promote equiaxed, fine grain structures throughout the cast alloy,thus avoiding formation of columnar crystals. Casting speed can also be increased. The wire feeder uses a variable frequency drive to control the motor, achieving stepless speed regulation. The motor drives the
drum via a reducer, and under the action of the pressing wheel, the wire is ejected. This main unit is equipped with a speed
setting device, a length setting device, and complete display functions, ensuring accurate counting, stable operation, small size,
and high power. It is an ideal wire feeding metallurgical equipment for small to medium-sized smelting industries.
Basic Description of the Equipment
1. Equipment Name: Wire Feeder
2. Equipment Model: WF-10

* WF:Wire Feeder

* 10: Aluminum-Titanium Wire Diameter
3. Equipment Purpose: Mainly used to inject alloy cored wire into molten aluminum at an appropriate speed and predetermined
quantity to achieve uniform dispersion, allowing for fine-tuning of the composition.Technical Parameters:

Motor power	Low Voltage Component From Zhengtai, VFD From SAJ
Rod Diameter	8-13mm
Feeding speed	1-2.5m/min, Variable Frequency Stepless Speed Regulation
Rod guide tube	2 Pieces
Feeding rod number	2 Rods
Feeding material	AlTiB Rod
