Product Details:
Place of Origin: Jinan, China
Brand Name: HYDEB
Certification: CE ISO9001
Model Number: HBQ-212
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: 700USD/set
Packaging Details: Standard exporting package
Delivery Time: 45 workdays
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 80 sets per year

Transfer Ladle Preheating Device Gas Fired / Electric Heating

Description
Material: Natural Gas Burner, Steel Color: According To Your Requirment
Ladle Cover: Customized Usage: Ladle Preheating
Heating Temperature: 900℃ Moving Method: Air Cylinder
High Light:

transfer ladle preheating equipment

,

Transfer Ladle Preheating Device

,

Electric Heating Preheating Device

Transfer Ladle Preheating Device Gas Fired/Electric Heating Preheating Device For Transfer Ladles Ladle Preheater

Manufacturer Gas Fired/Electric Heating Preheating Device for Transfer Ladles Ladle Preheater

USAGES

The transfer ladle preheating equipment, also known as ladle heater, is mainly used to quickly and uniformly increase the temperature of the molten aluminum ladle lining to reduce heat loss during molten aluminum pouring and prolong the service life of the molten aluminum ladle lining.



features



• Natural gas (NG) or LPG is chosen as the fuel.
• The heating speed can be adjusted within a wide range.
• Fully combusted, energy-saving and environment-friendly.
• Suitable for molten aluminum ladles of different heights.
• Equipped with a conventional high-speed gas burner and a self-preheating burner.
• Gas and combustion air pressure detection, abnormal ignition alarm.
• Heating temperature and time are controllable.
• Long open flame ignition function.

• Flame detection function.



Items Parameters Remarks
Modle HBQ-230
Heating Type Small; Medium; Big
Max. Burning Calorific Value 20x104 Kcal/h
Max Heating Temperature 1100℃
Working Heating Temperature 0-850℃
Heating Rate 0-50 ℃/min Adjustable
Time to Reach Temperature 0-60 min
Heating Temperature Uniformity ≤50 ℃
Lifting Power Air Cylinder Driver
Lifting Stroke 0-400mm
Gas Gas Type Natural Gas
Gas Pressure 5000 ±5% Pa
Gas Flow ≤24 m³/h
Power Voltage 380 V, 3P
Frequency 50HZ
Rated Power 3 KW
Compressed Air Pressure 0.5-0.7 MPa
Flow ≤50 M3/H


Transfer Ladle Preheating Device Gas Fired / Electric Heating 0Transfer Ladle Preheating Device Gas Fired / Electric Heating 1Transfer Ladle Preheating Device Gas Fired / Electric Heating 2Transfer Ladle Preheating Device Gas Fired / Electric Heating 3Transfer Ladle Preheating Device Gas Fired / Electric Heating 4
